The flagship of the Absolute Arm range, the Absolute Arm 7-Axis delivers tactile probing and laser scanning in a uniquely ergonomic package. It’s the clear choice for high-end portable measurement applications. With usability central to its design, this is an articulating measuring arm that can’t be beaten when it comes to ease of movement and ease of measurement.
Learn more about Portable Arm click here
Built-in versatility comes in the form of a uniquely modular wrist design, including an on-wrist display that puts control and results in the hands of the user. Choose between configurable grip shapes and sizes as well as a wide range of accessories, from probe tips and 3D optical scanners to complete measurement systems designed for specialised applications.
The flagship RS6 Laser Scanner is the key to high-end 3D scanning and digitisation, while our RS5 Laser Scanner offers established and reliable general-purpose scanning functionality. The ground-breaking RS-SQUARED Area Scanner offers a high-productivity alternative based on structured light scanning technology. Each can be quickly and easily mounted on the Absolute Arm 7-Axis by the user with no need for recalibration.
All this adds up to a far more productive and versatile arm that delivers high-accuracy measurement results more quickly and more easily than ever before
Absolute Arm 7-Axis, a great shop-floor solution of usability, versatility and productivity, is widely used in measuring 3D dimensions of machine frames, machine bodies, jigs, molds… Besides, Absolute Arm 7-Axis with extension of 3D scanner is a quick and high accuracy solution for inspecting 3D surfaces and reverse engineering.
Manufacturer of Hexagon Portable ABSOLUTE ARM 7-AXIS
V-PROUD Joint Stock Company, a distributor of Hexagon Manufacturing Intelligence, is authorized to provide Sales and support Technical services of Portable Absolute Arm 7-Axis in Vietnam.
V-PROUD Joint Stock Company is one of Vietnam’s leading companies in consulting
and providing complete solutions of precision metrology, quality control and quality assurance for industrial manufacturers.
Reference customers: VINFAST, SAMSUNG, FOXCONN, FUSHAN, VAPA, FORD, CNC HOLDING, JEIL TECH …
.png)
V-PROUD’s Customer Portfolio
Your benefits:
Being consulted enthusiastically, carefully based on in-depth knowledge of precision metrology, quality control and quality assurance
Receiving optimal solutions and equipment that meet the requirements and catch the developing trends of the industry to make the best advantage of customers’ investment.
Supported by the services team are trained by manufacturers as per international standard with reasonable costs.
Provided highly professional training to enhance personnel’s ability, stabilizing organization, optimizing equipment ‘s efficiency and system operation’s productivity.
Quick response, supporting online 24/7, on site within 48 hours.
Received financial consultation and support for small and medium enterprises.
Probing and Scanning
High-accuracy touch probing performance combined with high-end, high-productivity scanning in combination with the RS6 Laser Scanner or RS-SQUARED Area Scanner, the Absolute Arm 7-Axis is a multifunctional measurement tool that delivers clear productivity improvements through increased usability and versatility.
Absolute Encoders
The renowned Absolute Encoders placed in every articulated joint of the Absolute Arm make it the only portable measuring arm on the market to eliminate encoder referencing and frustrating system warm-up times, boosting productivity while delivering high-end accuracy.
Advanced Materials
Built on a foundation of high-tech carbon-fibre tube construction, the Absolute Arm maintains strength and thermal stability under any environmental conditions, offering reliable accuracy whatever the environment.
Configurable Wrist
The ergonomically designed wrist of the Absolute Arm 7-Axis features an OLED measurement display screen, interchangeable grips, exchangeable probe and scanner mountings and a selection of control buttons, making complete one-handed operational efficiency easier than ever before.
Effortless Movement
Intuitively located infinite-rotation low-friction grips have been designed to maximise accuracy by minimising user fatigue and making every movement light and easy to handle – together with a sophisticated counter balance system, the Absolute Arm is the most agile arm on the market.
Essential Security
Stow and lock in place the Absolute Arm between measurements with the Home Dock and Smart Lock functions, ensuring that scanners and probes remain undamaged and factory-accurate.
User Feedback
In even the harshest industrial environments, communicating with the Absolute Arm in a way that keeps the measurement process running at full speed and efficiency has never been more simple, through our range of visual, acoustic and haptic feedback functions.
Absolute Portability
Even the largest Absolute Arm 7-Axis systems weigh only 10.5 kilograms, making setup and repositioning a quick and easy process, while the functionally designed and shock-resistant carry case keeps everything secure during transport.
ISO Certification
The probing accuracy of the Absolute Arm 7-Axis is certified according to ISO 10360-12 as standard, with full scanning system accuracy certified according to ISO 10360-8 Annex D when supplied with an RS5 or RS6 Laser Scanner.
Technological Foundation
Built upon years of portable measuring arm technology, the Absolute Arm 7-Axis is the latest in a long line of market leading articulated measuring arms, from the ROMER Arm to the ROMER Absolute Arm and now beyond.
Absolute Arm 7-Axis accuracy and size specification
| Series | Model | EUNI | PSIZE | LDIA | PFORM | RS6 SSA5 | RS5 SSA5 | RS-SQUARED SSA5 |
Weight | Max. reach |
| 83 series | 8320-7 | 0.043 mm | 0.016 mm | 0.054 mm | 0.033 mm | 0.059 mm | 0.062 mm | NA | 8.8 kg | 2.48 m |
| 8325-7 | 0.048 mm | 0.023 mm | 0.060 mm | 0.043 mm | 0.065 mm | 0.068 mm | 0.164 mm | 9.1 kg | 2.98 m | |
| 8330-7 | 0.078 mm | 0.034 mm | 0.090 mm | 0.058 mm | 0.082 mm | 0.092 mm | 0.204 mm | 9.4 kg | 3.48 m | |
| 8335-7 | 0.092 mm | 0.042 mm | 0.115 mm | 0.067 mm | 0.099 mm | 0.105 mm | 0.242 mm | 9.7 kg | 3.98 m | |
| 8340-7 | 0.114 mm | 0.051 mm | 0.140 mm | 0.084 mm | 0.118 mm | 0.122 mm | 0.283 mm | 10.0 kg | 4.48 m | |
| 8345-7 | 0.158 mm | 0.078 mm | 0.168 mm | 0.106 mm | 0.163 mm | 0.172 mm | 0.338 mm | 10.3 kg | 4.98 m | |
| 85 series | 8520-7 | 0.029 mm | 0.010 mm | 0.038 mm | 0.021 mm | 0.041 mm | 0.045 mm | NA | 9.0 kg | 2.48 m |
| 8525-7 | 0.031 mm | 0.012 mm | 0.048 mm | 0.025 mm | 0.047 mm | 0.048 mm | 0.138 mm | 9.3 kg | 2.98 m | |
| 8530-7 | 0.057 mm | 0.020 mm | 0.083 mm | 0.038 mm | 0.064 mm | 0.066 mm | 0.168 mm | 9.6 kg | 3.48 m | |
| 8535-7 | 0.069 mm | 0.024 mm | 0.099 mm | 0.045 mm | 0.078 mm | 0.080 mm | 0.196 mm | 9.9 kg | 3.98 m | |
| 8540-7 | 0.084 mm | 0.030 mm | 0.120 mm | 0.050 mm | 0.089 mm | 0.091 mm | 0.228 mm | 10.2 kg | 4.48 m | |
| 8545-7 | 0.113 mm | 0.048 mm | 0.140 mm | 0.065 mm | 0.141 mm | 0.148 mm | 0.271 mm | 10.5 kg | 4.98 m | |
| 87 series | 8725-7 | 0.029 mm | 0.011 mm | 0.044 mm | 0.023 mm | 0.043 mm | 0.044 mm | 0.123 mm | 9.3 kg | 2.98 m |
| 8730-7 | 0.053 mm | 0.018 mm | 0.076 mm | 0.035 mm | 0.056 mm | 0.058 mm | 0.148 mm | 9.6 kg | 3.48 m | |
| 8735-7 | 0.064 mm | 0.022 mm | 0.092 mm | 0.041 mm | 0.068 mm | 0.071 mm | 0.173 mm | 9.9 kg | 3.98 m | |
| 8740-7 | 0.078 mm | 0.028 mm | 0.110 mm | 0.046 mm | 0.080 mm | 0.082 mm | 0.198 mm | 10.2 kg | 4.48 m | |
| 8745-7 | 0.104 mm | 0.044 mm | 0.125 mm | 0.060 mm | 0.121 mm | 0.127 mm | 0.222 mm | 10.5 kg | 4.98 m |
