The SIMSCAN 22 represents the pinnacle of advancement in handheld 3D scanning technology. Developed by SCANTECH, a reputable brand with extensive experience in the 3D scanning industry, SIMSCAN 22 is the perfect blend of compact design, high performance, and exceptional accuracy.

With a size of only 203 mm x 80 mm x 44 mm and a weight of 570 g, SIMSCAN 22 is one of the most portable 3D scanning devices available today, allowing easy operation in tight spaces or complex work environments. Its unibody metal shell not only ensures high durability but also enhances the aesthetic appeal and provides a sturdy feel during use.

SIMSCAN 22 is highly regarded not only for its design but also as a powerful tool for precise and rapid digitization. Equipped with a system of 22 blue laser lines, this device can capture up to 1,25 million measurements per second, offering maximum flexibility in data collection. The accuracy of up to 0.020 mm ensures that even the smallest details are captured, meeting the most stringent quality control requirements.

Optimized Space Design: With its compact size and lightweight, SIMSCAN 22 is easily usable in any work environment, from manufacturing plants to research laboratories.

Absolute Accuracy: SIMSCAN 22 achieves an accuracy of up to 0.020 mm, ideal for applications requiring high technical and quality standards.

Impressive Scanning Speed: The scanning speed of up to 1,25 million measurements per second optimizes time and reduces costs in production and inspection processes.

Multi-Industry Application: From automotive and aerospace to healthcare and heavy industries, SIMSCAN 22 is the ideal solution for complex 3D scanning needs.

Technical Features	SIMSCAN 22
Dimensions	203 mm x 80 mm x 44 mm
Weight	570 g
Accuracy	0.020 mm
Scanning Speed	1,25 million measurements/second
Number of Lasers	22 blue laser lines
Camera Distance	130 mm
Scanning Area Size	Up to 650 mm x 550 mm
Operating Temperature Range	-10°C to 40°C

SCANTECH is proud to be one of the leading manufacturers of 3D scanning solutions, aiming to deliver the most advanced technologies to serve a wide range of industrial sectors. With a reputation built on a commitment to quality and service, SCANTECH continually innovates to provide outstanding value to customers worldwide.

V-Proud - the official distributor of SCANTECH in Vietnam, is committed to providing not only high-quality products but also professional technical support services, ensuring to meet the most demanding needs of our customers.
