TRACKSCAN-P OPTICAL 3D TRACKING SCANNER

Vast Applications

• i-Tracker: Its measurement range can be dynamically extended by adding more i-Trackers so that it can measure large-scale objects without compromising accuracy.
• i-Probe:  It can be paired with a tracking T-Probe (optional with different sizes) to probe inaccessible areas such as holes and hidden points. This contact measurement probe can ensure precise results with high single-point repeatability of 0.030 mm.
• AM-CELL: It can be mounted on a robotic arm to form an automated 3D measurement system AM-CELL for efficient, and batch measurement.
• M-Track: Its i-Tracker can also be combined with path planning software for intelligent robotic path planning and guiding.

Precise Edge Detection

• TrackScan 3D tracking scanner features a stand-out function of instant edge detection. Users can inspect circles, grooves, and machined holes of stamping parts in various finishes on the site without having to import original CAD models.
• The efficient edge detection is enabled thanks to its gray value measurement and optional auxiliary light module. Good measurements are ensured by delivering accurate and repeatable hole positions and diameters.

Unrivaled-fast & Detail-maker: By freely switching between multiple working modes, the TrackScan fits different scanning situations with an accuracy of up to 0.025 mm and an ultra-fast measurement rate of up to 2,600,000 measurements/s. Its 7 parallel blue laser lines perform well for capturing details. A single blue laser line aims to collect 3D data of deep holes and hard-to-reach areas efficiently.

Optical Tracking for Instant 3D Scanning:TrackScan-P 3D system’s optical tracking allows users to start scanning instantly without having to stick targets, significantly improving efficiency and decreasing costs.

Strong Adaptability: Made from aerospace-grade materials, it is sturdy and reliable. It also boasts a strong anti-interference capability to operate smoothly regardless of vibrations or thermal variations. Due to its advanced algorithm, TrackScan is robust in capturing 3D data of reflective and dark surfaces.

SCANTECH (HANGZHOU) CO., LTD. is a global provider of comprehensive 3D solutions. We specialize in R&D, production, and sales of 3D scanners and 3D systems and boast a long history of developing hardware and software. We offer two main product categories: industrial high-precision 3D scanners and professional cost-effective 3D scanners, including portable 3D scanners, tracking 3D scanners, industrial automated 3D systems, and professional color 3D scanners.

Our products are widely used in industrial sectors such as aerospace, automotive, engineering machinery, transportation, 3C electronics, and green energy, as well as in digital application industries including education and research, 3D printing, art and museum, medical and health, public security and justice, virtual world, etc. We are dedicated to providing high-precision, portable, and intelligent 3D scanners to customers and striving to become a globally leading brand of 3D visual measurement.
