Mora 3D CMM Mora Primus 10128

Our bridge type measuring machine 3D CMM Primus presents a compact and stable machine concept, which is rounded by high-precision air bearing guidance and dynamic gears in all axes. A high-precision scale system in conjunction with a powerful controller guarantees the accuracy of the machine. By using granite in all axes, we ensure a constant thermal behavior of the coordinate measuring machine.

Our bridge type measuring machine 3D CMM Primus you can find in all divisions of the production and the quality assurance. If in the prototype construction or in run-production - the Primus is applicable universally.

Bridge type machine, CNC operation

- Granite plate, special high stiffness

- High accuracy natural stone guides

- Wearless precision air-cushion bearing guarantee smooth, low vibration movement

- Non-contact measuring system for high precision data acquisition on all axes, resolution 0,1 µm

- In MORA standard colours

Bridge type machine, CNC operation

- Granite plate, special high stiffness

- High accuracy natural stone guides

- Wearless precision air-cushion bearing guarantee smooth, low vibration movement

- Non-contact measuring system for high precision data acquisition on all axes, resolution 0,1 µm

- In MORA standard colours

- Primus is compatible with various probe systems

#Mora

#CMM #3DCMM #maydotoado #hexagon #mitutoyo #dukin #mora #kreon #renishaw #coordinate #coordinatemeasuringmachine

Measuring ranges and accuracy:

Type

Machine size (mm)

Size work plate

(mm)



Lx

Ly

Lz

Px

Py

Pz

H

10128

2005

2320

3325

1380

2020

300

740



Accuracy of Mora 3D CMM Mora Primus From: 1,3 + l/300

The stated accuracy true for the smallest measuring range and for a surrounding temperature of 20° C. Special sizes and special accuracies available on request.

Probe Systems

- Primus is compatible with various probe systems:

Options

- Active pneumatic shock absorption

- Active temperature compensation in all axes incl. workpiece

- Air preparation facilities (e. g. air dryer)

- Delivery systems and palletising systems

Handbox

- Cable handbox

- Wireless handbox

Software

- Inca3D software options

- Customer specific software training

MORA provide products for all applications of the industrial measuring technology.

Whether you are from the vehicle manufacturing, the aerospace, the plastic industries or from the general machine building industries, you will find a solution for your measuring tasks at MORA Metrology GmbH.
